Tower Crane Models - CALL FOR AVAILABILITY

green bar

Vicario 1785/78 "Fast"

  • 1,655 lbs @ 85′ radius
  • 4,851 lbs @ 35′ radius
  • 78′ hook height
  • Self-contained on one truck – counterweights swing forward and travel mounted on the crane, making set up, relocation, and tear down more efficient
  • 13’9″Wx13’9″L footprint
  • Operates on single phase or three phase power
green bar
14 ton stinger crane

Vicario 2298/78

  • 2,205 lbs @ 98′ radius
  • 8,820 lbs @ 31′ radius
  • 78′ hook height
  • 13’3″Wx13’3″L footprint
  • Operates on single phase or three phase power
green bar

VIcario 17102/72 "Fast"

  • 1,750 lbs @ 102′ radius
  • 6,600 lbs @ 35′ radius
  • 72′ Hook height
  • Self-contained on one truck – counterweights swing forward and travel mounted on the crane, making set up, relocation, and tear down more efficient
  • 15’9″Wx15’9″L footprint
  • Operates on single phase or three phase power

green bar
14 ton stinger crane

Potain IGO50

  • 2,425 lbs @ 131′ radius
  • 8,820 lbs @ 42′ radius
  • 76′ hook height
  • Transported in two legal loads
  • 19’Wx19’L footprint
  • Operates on 480V three phase power
  • Two identical cranes in fleet
green bar
14 ton stinger crane

Vicario 22137/85

  • 2,205 lbs @ 137′ radius
  • 8,820 lbs @ 45′ radius
  • 85′ hook height
  • 14’9″Wx14’9″L footprint
  • Operates on single phase or three phase power
  • Two identical cranes in fleet
green bar
14 ton stinger crane

Vicario 22147/92

  • 2,205 lbs @ 147′ radius
  • 8,820 lbs @ 47′ radius
  • 92′ hook height
  • 16’6″Wx16’6″L footprint
  • Operates on single phase or three phase power
green bar

Potain HDT80

  • 2,976 lbs @ 148′ radius
  • 13,228 lbs @ 44′ radius
  • 112′ hook height
  • 15’Wx15’L footprint
  • Operates on three phase power

green bar

Saez TL-55

  • Traditional city tower crane
  • 2,646 lbs @ 180′ radius
  • 11,025 lbs @ 49′ radius
  • 166′ maximum hook height with 14’9″Wx14’9″L footprint
  • 100′ maximum hook height with 12’6″Wx12’6″L footprint
  • Operates on three phase power
